Stainless Steel 180 Degree Elbows
Technology: Mandrel forming
Stardard: ASMEB16.9,DIN2605,JIS
Size: Seamless Elbow ( 1/2″～24″)
Welded(1/2″～48″)
Type: Seamless /Welded
Thickness: SCH5S-SCH160
Standard: ASMEB16.9,DIN2605,JIS B2313,GB/T12459,GB/T13401,SH3408,SH3409,HG/T21635,HG/T21631,MSS SP-43
Materials: 317/L、304/L、316/L 、310/S 、309/S、347/H 、321/321H、904/L 、S32750/F53/SAF2507、S32205/F60 S31803/F51、S32760/F55
Description
Stainless Steel 180 Degree Elbows is made of high-quality stainless steel. Elbow is a commonly used connection pipe fitting in pipeline installation. It connects two pipes with the same or different nominal diameters to make the pipeline turn at a certain angle.
| Nominal Diameter |
Outside Diameter |
Center to Center |
Back to End | |||
| O | K | |||||
|
DN |
INCH |
mm |
L/R |
S/R |
L/R |
S/R |
|
15 |
1/2" |
21.3 |
76 |
- |
48 |
- |
|
20 |
3/4" |
26.9 |
76 |
- |
51 |
- |
|
25 |
1" |
33.7 |
76 |
51 |
56 |
41 |
|
32 |
11/4" |
42.4 |
95 |
64 |
70 |
50 |
|
40 |
11/2" |
48.3 |
114 |
76 |
80 |
62 |
|
50 |
2" |
60.3 |
150 |
102 |
106 |
81 |
|
65 |
21/2" |
76.1(73) |
190 |
120 |
132 |
100 |
|
80 |
3" |
88.9 |
229 |
150 |
159 |
12 |
|
90 |
31/2" |
101.6 |
260 |
178 |
184 |
140 |
|
100 |
4" |
114.3 |
305 |
203 |
210 |
159 |
|
125 |
5" |
139.7 |
381 |
254 |
262 |
197 |
|
150 |
6" |
168.3 |
457 |
305 |
313 |
237 |
|
200 |
8" |
219.1 |
600 |
406 |
414 |
313 |
|
250 |
10" |
273 |
762 |
508 |
518 |
391 |
|
300 |
12" |
323.9 |
914 |
600 |
609 |
460 |
|
350 |
14" |
355.6 |
1060 |
711 |
711 |
503 |
|
400 |
16" |
406.4 |
1219 |
813 |
813 |
600 |
|
450 |
18" |
457.2 |
1360 |
914 |
914 |
686 |
|
500 |
20" |
508 |
1504 |
1016 |
1016 |
762 |
|
550 |
22" |
559 |
1606 |
1118 |
1118 |
808 |
|
600 |
24" |
600 |
1829 |
1219 |
1219 |
914 |
Application
Stainless Steel 180 Degree Elbows are widely used in basic projects such as Oil and Gas Pipeline, Chemical Industry, Plumbing, Heating, Water Supply Systems, Power Plant, Paper & Pulp Industry, General Purpose Applications, Fabrication Industry, Food Processing Industry in Structural Pipe, etc.
Why do you choose us to cooperate?
-
The products with high quality and smooth surface is easy to sell for you;
-
Our quoting prices are benifitful for your developing your markets;
-
The service from our professional exporting team will help you during Pre-sales, in-sales and after-sales;
-
We pay attention to our cooperation to bring you value, pleasure and friendship.
Our Company
Exhibition Photos
Shipping & Payment
Product sales area: The most countries of Asia, Europe, Africa, South America and North America.
Packaging: General exporting cartons+pallets (if customer requests)
Transport method: By sea, by air or by rail (samples by express)
MOQ: 500PCS each item
Payment terms: T/T or L/CIf you want to know more information, please contact sales2@cx-hoses-fittings.com
