Stainless Steel Solenoid Liquid Air Oil Solenoid Valve
Product Name：Solenoid Valve
Working Temperature：-5 ~ 80℃
Material：Stainless steel
Fluid：Air , water, oil, gas
Operating Pressure：Water: 0-0.5Mpa / Air:0-0.7 Mpa / Oil:0-0.5Mpa / Gas:0-0.7Mpa
Max.pressure：1.05Mpa
Action Type：Direct Drive Type
Voltage Range ：+- 10%
Operation Fluid Viscosity：20 CST
Description
Products Description
Stainless Steel Solenoid Liquid Air Oil Solenoid Valve
Solenoid valve is an industrial equipment controlled by electromagnetism, is used to control the fluid automation basic components, belongs to the actuator, and is not limited to hydraulic, pneumatic. Used in industrial control systems to adjust the direction of the medium, flow, speed and other parameters.
| Motion Pattem: | Guide Type |
| Control Type: | Nomally Closde |
| Joint Pipe Bore: | G1~G3 |
| Aperture of Flow Rate: | DN25~DN80 |
| Warking-pressure: | 0.25~16bar |
| Applicable Fluid: | Neutral gas or liquid,steam |
| Fluid Viscosity: | ≤21mm2/s |
| Fluid Temperature: | -10~+80°C |
| Ambient Temperature: | -10~+50°C |
| Body material: | Stainless steel 304 |
| Seals material: | NBR FPM EPDM |
| Standard Voltage: | AC:220V(50/60Hz) AC110V DC2V |
| Protection Class: | IP65 |
| Model NO. | A | B | C |
| 2W-160-10B | 69 | 57 | 107 |
| 2W-160-15B | 69 | 57 | 107 |
| 2W-200-20B | 73 | 57 | 115 |
| 2W-250-25B | 98 | 77 | 125 |
| 2W-320-32B | 115 | 87 | 153 |
| 2W-400-40B | 124 | 94 | 162 |
| 2W-500-50B | 168 | 123 | 187 |
Solenoid valves can be used with different circuits to achieve the desired control, while the precision and flexibility of control can be guaranteed.
If you want to know more information, please contact sales2@cx-hoses-fittings.com.
