Brass Parallel Needle Valve For Gas Max Pressure
Temperature of Media：Low Temperature, Medium Temperature, Normal Temperature
Media Water
Product name: Brass needle valve
Working pressure: 1mpa
Handle: handwheel
Connection: Female x female
Size: 1/4"
Structure: needle
Hose barbed OD: 12.5mm
Description
Products Description
Brass Parallel Needle Valve for Gas Max Pressure
Needle valve is a valve with a small port and a threaded needle plunger. It allows precise adjustment of the flow rate, although it can usually only be used for relatively low flow rates.
|
Type |
Gate Valves, Water Heater Service Valves, Gas Appliance Isolation Shut-Off Valves, Kitchen Gas Shut-Off Valves, Water Pressure Reducing Valves, Water Regulating Valves |
|
Customized support |
OBM |
|
Application |
General |
|
Temperature of Media |
High Temperature |
|
Power |
Manual |
|
Media |
Gas |
|
Port Size |
customize |
|
Structure |
BALL |
|
Standard or Nonstandard |
Standard |
|
Color |
GOLD |
Needle valves are commonly used in flow metering applications, especially when a constant, calibrated low flow rate must be maintained for a period of time.It uses a blunt, tapered needle, but it rests on a square-edged seat rather than a matching taper. The object here is to obtain a well-defined seat between two narrow mating surfaces that will securely shut off the flow by only a slight floating pressure. Needle valves are also commonly used in anhydrous ammonia (NH3) applications to shut off pressure gauges or applicators to shut off the NH3 supply to the tool.
Needle valves are not used for simple shutoff applications due to low flow rates and the need to turn the stem several times to fully open or close. Due to the small orifice and the high force advantage of the fine threaded stem, needle valves are usually easy to close completely, requiring only hand tightening. Needle valve spindles and/or seats, especially those made of brass, are easily damaged by excessive rotational forces when shutting off flow. Small, simple needle valves are often used as bleeder valves in water heating applications. Unlike ball valves or valves with a rising stem, it is difficult to tell if the valve is open or closed by examining the handle position.
If you want to know more information, please contact sales2@cx-hoses-fittings.com.
